The CVSmart® is the new reference in CVS analysis of organic components. The system can analyze Carrier (Wetter), Brightener and Leveller. The CVSmart® can be used as a manual lab equipment or together with an autodosing unit the DOSmart®.
The T100 is from our CVS range and is capable of multiple sample analysis.
Fully automated system capable of running 17 samples.
Additions of standard solutions and production samples is automatic.
Fresh DI water rinse between analysis.
Completely open and programmable analysis.
Able to run different types of analysis using the same program.
Can run, for example, Carrier / Brightener / Leveler analysis on the same carrousel.
Uses the same software as CVSmart® for control.
Multisample CVS unit
3 Electrodes system
DI water shower position for the rinsing of the electrodes
Capability to analyze all your organic components on the same carrousel
Windows-based software, ease-of-use
Automatic saving of the result in an Excel file
Automatic preparation of Intercept and Support Electrolyte solutions
Automatic addition of VMS
T100 + Eng-HR.pdf
This electrochemical analyser is the latest generation of CVS device.
This instrument automatically analyses the organics additives directly from the plating line and makes automatic additions based on the results.
ONLINE CVS AND Cu/H2SO4 /Cl- MONITORING UNIT
Continuous analysis of Carrier, Brightener and Leveler
Continuous analysis of Copper, Sulfuric Acid and Chloride
Automatic replenishment of the plating additives based on the analysis results
Ethernet Hub for Analysis results and Alarms transfer to the central system
